Epson EB-760W

4.100 Lumen- 2.800 Lumen , WXGA, 2.500.000 : 1, Laser, 263 Wat, AC 100 V - 240 V, 50 Hz - 60 Hz, 356‎ x 395 x 133 mm, 5900 g

Key Features

• Scalable HD display for any room: 53-150" UST display for unrestricted viewing (no shadows/reflections)
• Bright and energy efficient laser: 4,100lm CLO with 3LCD technology for brighter colours at only 205W
• Effortless connectivity options: Auto-on, wired / wireless display with USB 2A output for smart sticks
• Simple to use and built to last: Virtually maintenance free with 5-year, 12,000hr warranty
• Document camera compatibility: Create and record a live, totally immersive lesson or presentation

Reasons To Buy

Legal Statement

Complies with The UK Product Security and Telecommunications Infrastructure (Product Security) requirements. Epson will provide security updates for 7 years from purchase

Description

Agile UST laser display
Whatever the size of class or meeting room, unrestricted and immersive presentations are possible with this bright, clear, compact and affordable display solution.

The EB-760W's bright image, scalable up to 150", is clearly visible from any angle and from a distance, and content can be easiliy shared or streamed directly from multiple devices for the perfect collaborative experience.


The EB-760W's ultra short throw lens allows safe, discreet positioning close to the display, enabling presenters free access to perform without casting shadows.


With 4,100 lumens Colour Light Output and Epson 3LCD technology, the display is bright and vibrant up-to 150", clearly visible from all angles and from a distance. The experience is immersive and user-friendly.


Projection also enables flexible display sizes, scalable from 49-150", display sizes can be optimised for each room with one familiar product and at a fixed cost


Versatile wired and wireless connectivity options, including screen mirroring via Miracast™, allow participants to effortlessly share content from their PCs or mobile devices. With a connected optional Epson visualiser, documents, presentations or 3D objects can be viewed with incredible detail.


Unlike a flat-panel display, there is no heavy, breakable, glass panel to create disruptive, reflected blind spots at certain angles, and teachers are not subjected to LCD panel direct blue light radiation, believed to damage eyes. Paired with a hygienic, antibacterial whiteboard, teachers can annotate presentations with dry-wipe pens, or to save energy, simply use the whiteboard with the display turned off.

Specifications

Projector
Number of colours	1.07 billion colours
Projector native resolution	WXGA (1280x800)
Native aspect ratio	16:10
Supported aspect ratios	16:10
Screen size compatibility	1524 - 3810 mm (60 - 150")
Contrast ratio (typical)	2500000:1
Contrast ratio (dynamic)	5000000:1
Zoom ratio	1.35:1
Zoom capability	Yes
Vertical scan range	100 - 120 Hz
Projector brightness (economic mode)	2800 ANSI lumens
Keystone correction, vertical	±3°
Keystone correction, horizontal	±3°
Projection technology	3LCD
Projector brightness	4100 ANSI lumens
Heat dissipation	895 BTU/h
Lamps
Light source type	Laser
Service life of light source	20000 h
Service life of light source (economic mode)	30000 h
Light source
Light source type	Laser
Service life of light source	20000 h
Service life of light source (economic mode)	30000 h
Lens system
Fixed focal length	3.7 mm
Zoom ratio	1.35:1
Zoom capability	Yes
Focus	Manual
Focal length range	3.7 mm
Throw ratio	0.27 - 0.37:1
F-number (relative aperture)	1.6
Scanning frequency
Vertical scan range	100 - 120 Hz
Video
Video processing	10 bit
Video colour modes	Blackboard, Cinema, Dynamic, Presentation, sRGB
Full HD	No
3D	No
Audio
Built-in speaker(s)	Yes
RMS rated power	16 W
Ports & interfaces
USB 2.0 Type-B ports quantity	1
VGA (D-Sub) ports quantity	2
HDMI ports quantity	3
Ethernet LAN (RJ-45) ports	1
USB 2.0 ports quantity	3
Composite video in	1
Audio (L/R) in	3
Audio (L/R) out	1
Microphone in	Yes
Serial interface type	RS-232C
DVI port	No
Component video (YPbPr/YCbCr) in	0
Audio Return Channel (ARC)	Yes
Consumer Electronics Control (CEC) support	Yes
USB 2.0 Type-A ports quantity	2
Network
Ethernet LAN	Yes
Ethernet LAN data rates	10,100 Mbit/s
Wi-Fi	Yes
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Ethernet LAN (RJ-45) ports	1
Miracast	Yes
Storage
Card reader integrated	No
Sound emission
Noise level	37 dB
Noise level (economic mode)	27 dB
Technical details
Product colour	White
On Screen Display (OSD)	Yes
Security features	Kensington lock, Control panel lock, Padlock, Security cable hole, Wireless LAN unit lock, Wireless LAN security, Password protection
Option type	Air filter, Ceiling mount, Connection and control box, External Speaker, Safety wire set, Visualiser camera, WP System - ELPWP10, Wall mount, Wireless LAN unit, Wireless transmitter - ELPWT01
Heat dissipation	895 BTU/h
Control panel	0.59 inch with C2 Fine
Box contents	Power cable, Projector feet, Quick Start Guide, Remote control incl. batteries, Warranty document
Products per pallet	12 pc(s)
Quantity per pack	1 pc(s)
Pallet gross width	80 cm
Pallet gross length	120 cm
Pallet gross height	2.1 m
Products per pallet layer (UK)	4 pc(s)
Products per pallet layer	2 pc(s)
Products per pallet (UK)	24 pc(s)
Pallet length (UK)	120 cm
Pallet height (UK)	2.1 m
Other features	A/V mute, Arc Correction, Auto Power On, Auto source search, Built-in speaker, CEC compatible, Customizable user logo, Digital zoom, Direct Power on/off, Document Camera Compatible, Email notification, Home Screen, Horizontal and vertical keystone correction, Image Shift, JPEG Viewer, Long light source life, Network projection, OSD copy function, PC Free, Power on button, Quick Corner, Schedule Function, Screen Mirroring, Ultra-wide display (16:6), Web Control, Web Remote, Wireless LAN capable, iProjection App
Warranty period	5 year(s)
Mobile app support	Yes
Power consumption	197 Watt (Normal On-Mode), 141 Watt (Eco On-Mode), 263 Watt (Normal Peak-mode), 199 Watt (Eco Peak-Mode), 0.5 Watt (Energy saving standby)
Performance
Market positioning	Presentation
Password protection	Yes
On Screen Display (OSD)	Yes
Vertical scan range	100 - 120 Hz
Noise level	37 dB
Noise level (economic mode)	27 dB
Heat dissipation	895 BTU/h
Screen mirroring	Yes
Features
Password protection	Yes
On Screen Display (OSD)	Yes
Noise level	37 dB
Noise level (economic mode)	27 dB
Screen mirroring	Yes
Country of origin	Philippines
Multimedia
Built-in speaker(s)	Yes
RMS rated power	16 W
Design
Market positioning	Presentation
Product type	Ultra short throw projector
Cable lock slot type	Kensington
Product colour	White
Cable lock slot	Yes
Placement	Ceiling, Desktop, Wall
Display
Built-in display	No
Power
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	263 W
Power source	AC
Power consumption (typical)	197 W
Power consumption (standby)	0.5 W
Power consumption (PowerSave)	199 W
Packaging data
Package width	450 mm
Package depth	485 mm
Package height	325 mm
Package weight	8.74 kg
Security
Cable lock slot type	Kensington
Cable lock slot	Yes
Software
Bundled software	EasyMP Multi PC Projection, Epson Classroom Connect, Epson Projector Content Manager, Epson Projector Management
Supplier features
Recommended gender	Any gender
Operational conditions
Operating relative humidity (H-H)	20 - 80%
Storage temperature (T-T)	-10 - 60 °C
Storage relative humidity (H-H)	10 - 90%
Weight & dimensions
Package width	450 mm
Package depth	485 mm
Package height	325 mm
Weight	5.9 kg
Width	356 mm
Depth	395 mm
Height	133 mm
Package weight	8.74 kg
Packaging content
Remote control included	Yes
Manual	Yes
Cables included	AC
Bundled software	EasyMP Multi PC Projection, Epson Classroom Connect, Epson Projector Content Manager, Epson Projector Management
Batteries included	Yes
Logistics data
Products per pallet	12 pc(s)
Quantity per pack	1 pc(s)
Pallet gross width	80 cm
Pallet gross length	120 cm
Pallet gross height	2.1 m
Products per pallet layer (UK)	4 pc(s)
Products per pallet layer	2 pc(s)
Products per pallet (UK)	24 pc(s)
Pallet length (UK)	120 cm
Pallet height (UK)	2.1 m
Other features
Supported network protocols	HTTPS, IPv4, IPv6, SNMP, ESC/VP.net, PJLink
Security features	Kensington lock, Control panel lock, Padlock, Security cable hole, Wireless LAN unit lock, Wireless LAN security, Password protection
Interface	USB 2.0-A (2x), RS-232C, Ethernet interface (100 Base-TX / 10 Base-T), Wireless LAN IEEE 802.11a/b/g/n/ac, VGA in (2x), VGA out, HDMI in (3x), Composite in, Miracast, Jack plug out, Jack plug in (3x), USB 2.0 Type B (Service Only), Wi-Fi Direct, Microphone input
F-number (relative aperture)	1.6
Option type	Air filter, Ceiling mount, Connection and control box, External Speaker, Safety wire set, Visualiser camera, WP System - ELPWP10, Wall mount, Wireless LAN unit, Wireless transmitter - ELPWT01
Control panel	0.59 inch with C2 Fine
Box contents	Power cable, Projector feet, Quick Start Guide, Remote control incl. batteries, Warranty document
