Epson EB-770F
Epson EB-770F
Regular price
£1,769.52 GBP
Regular price
Sale price
£1,769.52 GBP
Taxes included.
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
EB-770F
Whatever the size of class or meeting room, unrestricted and immersive presentations are possible with this bright, clear, compact and affordable display solution.
The EB-770F's bright, 1080p image, scalable up to 150", is clearly visible from every angle and at a distance, and content can easiliy be shared or streamed directly from multiple devices for the ultimate collaborative experience.
The EB-770F's ultra short throw lens allows safe, discreet positioning close to the display, enabling presenters free access to perform without casting shadows.
With 4,100 lumens CLO and 3LCD technology, the display is bright and vibrant up to 150", clearly visible from all angles and at a distance. The experience is immersive and user-friendly.
Scalable from 49-150", display sizes can be optimised for each room with one product and a fixed cost, and the EB-770F supports multi-projection edge-blending for a low cost, large, seamless, energy efficient 3780x1080p image.
Versatile wired and wireless connectivity options, including Miracast™ screen mirroring, ensures effortless, multi-device content sharing, and with a connected optional Epson visualiser, documents, presentations or 3D objects can be projected in incredible detail to the whole room.
Unlike a flat-panel display, there is no heavy, breakable, glass panel to create disruptive, reflected blind spots at certain angles, and teachers are not subjected to LCD panel direct blue light radiation, believed to damage eyes. Paired with a hygienic, antibacterial whiteboard, teachers can annotate presentations with dry-wipe pens, or to save energy, simply use the whiteboard with the display turned off.
Key Features
- Scalable FHD display for any room: 49-150" UST display for unrestricted viewing (no shadows/reflections)
- Bright and energy efficient laser: 4,100lm CLO with 3LCD technology for brighter colours at only 205W
- Effortless connectivity options: Auto-on, wired / wireless display with USB 2A output for smart sticks
- Simple to use and built to last: Virtually maintenance free with 5-year, 12,000hr warranty
- Document camera compatibility: Create and record a live, totally immersive lesson or presentation
Reasons To Buy
Legal Statement
Complies with The UK Product Security and Telecommunications Infrastructure (Product Security) requirements. Epson will provide security updates for 7 years from purchaseDescription
Agile UST laser displayWhatever the size of class or meeting room, unrestricted and immersive presentations are possible with this bright, clear, compact and affordable display solution.
The EB-770F's bright, 1080p image, scalable up to 150", is clearly visible from every angle and at a distance, and content can easiliy be shared or streamed directly from multiple devices for the ultimate collaborative experience.
The EB-770F's ultra short throw lens allows safe, discreet positioning close to the display, enabling presenters free access to perform without casting shadows.
With 4,100 lumens CLO and 3LCD technology, the display is bright and vibrant up to 150", clearly visible from all angles and at a distance. The experience is immersive and user-friendly.
Scalable from 49-150", display sizes can be optimised for each room with one product and a fixed cost, and the EB-770F supports multi-projection edge-blending for a low cost, large, seamless, energy efficient 3780x1080p image.
Versatile wired and wireless connectivity options, including Miracast™ screen mirroring, ensures effortless, multi-device content sharing, and with a connected optional Epson visualiser, documents, presentations or 3D objects can be projected in incredible detail to the whole room.
Unlike a flat-panel display, there is no heavy, breakable, glass panel to create disruptive, reflected blind spots at certain angles, and teachers are not subjected to LCD panel direct blue light radiation, believed to damage eyes. Paired with a hygienic, antibacterial whiteboard, teachers can annotate presentations with dry-wipe pens, or to save energy, simply use the whiteboard with the display turned off.
Specifications
| Projector | |
|---|---|
| Number of colours | 1.07 billion colours |
| Projector native resolution | 1080p (1920x1080) |
| Native aspect ratio | 16:9 |
| Screen size compatibility | 1524 - 3810 mm (60 - 150") |
| Contrast ratio (typical) | 2500000:1 |
| Contrast ratio (dynamic) | 5000000:1 |
| Zoom ratio | 1.35:1 |
| Zoom capability | Yes |
| Vertical scan range | 192 - 240 Hz |
| Projector brightness (economic mode) | 2800 ANSI lumens |
| Keystone correction, vertical | ±3° |
| Keystone correction, horizontal | ±3° |
| Projection technology | 3LCD |
| Projector brightness | 4100 ANSI lumens |
| Heat dissipation | 895 BTU/h |
| Lamps | |
| Light source type | Laser |
| Service life of light source | 20000 h |
| Service life of light source (economic mode) | 30000 h |
| Light source | |
| Light source type | Laser |
| Service life of light source | 20000 h |
| Service life of light source (economic mode) | 30000 h |
| Lens system | |
| Zoom ratio | 1.35:1 |
| Zoom capability | Yes |
| Focus | Manual |
| Focal length range | 3.7 mm |
| Throw ratio | 0.25 - 0.35:1 |
| F-number (relative aperture) | 1.6 |
| Scanning frequency | |
| Vertical scan range | 192 - 240 Hz |
| Video | |
| Video processing | 10 bit |
| Video colour modes | Blackboard, Cinema, DICOM simulation mode, Dynamic, Multi-projection, Presentation, sRGB |
| Audio | |
| Built-in speaker(s) | Yes |
| Number of built-in speakers | 1 |
| RMS rated power | 16 W |
| Ports & interfaces | |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 0 |
| USB 2.0 Type-B ports quantity | 1 |
| VGA (D-Sub) ports quantity | 2 |
| HDMI ports quantity | 3 |
| USB 2.0 ports quantity | 0 |
| Composite video in | 1 |
| Headphone outputs | 1 |
| Component video (YPbPr/YCbCr) in | 0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 0 |
| Mini-USB 2.0 ports quantity | 0 |
| Audio Return Channel (ARC) | No |
| USB 2.0 Type-A ports quantity | 2 |
| Network | |
| Ethernet LAN | Yes |
| Wi-Fi | Yes |
| Bluetooth | No |
| Sound emission | |
| Noise level | 37 dB |
| Noise level (economic mode) | 27 dB |
| Technical details | |
| Product colour | White |
| HDCP | No |
| Security features | Kensington lock, Control panel lock, Padlock, Security cable hole, Wireless LAN unit lock, Wireless LAN security, Password protection |
| Option type | Air filter, Ceiling mount, Connection and control box, External Speaker, Safety wire set, Visualiser camera, WP System - ELPWP10, Wall mount, Wireless LAN unit, Wireless transmitter - ELPWT01 |
| Heat dissipation | 895 BTU/h |
| Control panel | 0.62 inch with C2 Fine |
| Box contents | Power cable, Projector feet, Quick Start Guide, Remote control incl. batteries, Warranty document |
| Products per pallet | 12 pc(s) |
| Quantity per pack | 1 pc(s) |
| Pallet gross width | 80 cm |
| Pallet gross length | 120 cm |
| Pallet gross height | 2.1 m |
| Products per pallet layer (UK) | 4 pc(s) |
| Products per pallet layer | 2 pc(s) |
| Products per pallet (UK) | 24 pc(s) |
| Pallet length (UK) | 120 cm |
| Pallet height (UK) | 2.1 m |
| Other features | 21:9 aspect ratio support, A/V mute, Arc Correction, Auto Power On, Auto source search, Built-in speaker, CEC compatible, Customizable user logo, Digital zoom, Direct Power on/off, Document Camera Compatible, Edge Blending, Email notification, Home Screen, Horizontal and vertical keystone correction, Image Shift, JPEG Viewer, Long light source life, Network projection, OSD copy function, PC Free, Point correction, Power on button, Quick Corner, Schedule Function, Screen Mirroring, Split-Screen-Function, Ultra-wide display (16:6), Web Control, Web Remote, Wireless LAN capable, iProjection App |
| Mobile app support | Yes |
| Power consumption | 197 Watt (Normal On-Mode), 141 Watt (Eco On-Mode), 263 Watt (Normal Peak-mode), 199 Watt (Eco Peak-Mode), 0.5 Watt (Energy saving standby) |
| TV tuner | |
| TV tuner integrated | No |
| Performance | |
| Password protection | Yes |
| HDCP | No |
| Vertical scan range | 192 - 240 Hz |
| Noise level | 37 dB |
| Noise level (economic mode) | 27 dB |
| Heat dissipation | 895 BTU/h |
| Screen mirroring | Yes |
| Features | |
| Password protection | Yes |
| HDCP | No |
| Noise level | 37 dB |
| Noise level (economic mode) | 27 dB |
| High Dynamic Range (HDR) supported | No |
| Screen mirroring | Yes |
| Country of origin | Philippines |
| Multimedia | |
| Built-in speaker(s) | Yes |
| Number of built-in speakers | 1 |
| TV tuner integrated | No |
| RMS rated power | 16 W |
| Design | |
| Cable lock slot type | Kensington |
| Product colour | White |
| Cable lock slot | Yes |
| Placement | Ceiling, Desktop, Wall |
| Display | |
| Built-in display | No |
| Power | |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Power source | AC |
| Power consumption (typical) | 197 W |
| Power consumption (standby) | 0.5 W |
| Packaging data | |
| Package width | 450 mm |
| Package depth | 485 mm |
| Package height | 325 mm |
| Package weight | 8.73 kg |
| Security | |
| Cable lock slot type | Kensington |
| Cable lock slot | Yes |
| Software | |
| Bundled software | Epson Creative Projection, EasyMP Multi PC Projection, Epson BarCode Fonts, Epson Classroom Connect |
| Operational conditions | |
| Operating relative humidity (H-H) | 20 - 80% |
| Storage temperature (T-T) | -10 - 60 °C |
| Storage relative humidity (H-H) | 10 - 90% |
| Weight & dimensions | |
| Package width | 450 mm |
| Package depth | 485 mm |
| Package height | 325 mm |
| Weight | 5.9 kg |
| Width | 356 mm |
| Depth | 395 mm |
| Height | 133 mm |
| Package weight | 8.73 kg |
| Packaging content | |
| Remote control included | Yes |
| Cables included | AC |
| Bundled software | Epson Creative Projection, EasyMP Multi PC Projection, Epson BarCode Fonts, Epson Classroom Connect |
| Logistics data | |
| Products per pallet | 12 pc(s) |
| Quantity per pack | 1 pc(s) |
| Pallet gross width | 80 cm |
| Pallet gross length | 120 cm |
| Pallet gross height | 2.1 m |
| Products per pallet layer (UK) | 4 pc(s) |
| Products per pallet layer | 2 pc(s) |
| Products per pallet (UK) | 24 pc(s) |
| Pallet length (UK) | 120 cm |
| Pallet height (UK) | 2.1 m |
| Other features | |
| Supported network protocols | HTTPS, IPv4, IPv6, SNMP, ESC/VP.net, PJLink |
| Security features | Kensington lock, Control panel lock, Padlock, Security cable hole, Wireless LAN unit lock, Wireless LAN security, Password protection |
| Interface | USB 2.0-A (2x), RS-232C, Ethernet interface (100 Base-TX / 10 Base-T), Wireless LAN IEEE 802.11a/b/g/n/ac, VGA in (2x), VGA out, HDMI in (3x), Composite in, Miracast, Jack plug out, Jack plug in (3x), USB 2.0 Type B (Service Only), Wi-Fi Direct, Microphone input |
| F-number (relative aperture) | 1.6 |
| Option type | Air filter, Ceiling mount, Connection and control box, External Speaker, Safety wire set, Visualiser camera, WP System - ELPWP10, Wall mount, Wireless LAN unit, Wireless transmitter - ELPWT01 |
| Control panel | 0.62 inch with C2 Fine |
| Box contents | Power cable, Projector feet, Quick Start Guide, Remote control incl. batteries, Warranty document |
